Linuxautofs自动挂载详解与实现攻略

时间:2025-05-06 22:13:03 159浏览 收藏

Linux自动挂载autofs详解及实现方法:autofs服务可以实现对外部设备和NFS共享目录的自动挂载,并在空闲5分钟后自动卸载。本文详细介绍了autofs的安装、配置和使用方法,包括如何通过autofs实现光盘和NFS共享的自动挂载。此外,还介绍了如何使用tuned工具优化Linux系统性能,提供了多种调整配置文件的选择和应用方法,帮助系统管理员根据具体需求提升系统性能。

Linux实现自动挂载autofs的方法详解

目录
  • 实现自动挂载-autofs

  • autofs工具简单使用

  • autofs配置详细说明

  • 自动挂载资源有两种格式

  • 优化Linux系统性能

  • 安装Tuned

  • 选择调整配置文件

  • 检查系统推荐的调整配置文件

实现自动挂载-autofs

autofs服务可以实现对外部设备、NFS共享目录等的自动挂载,并在空闲5分钟后自动卸载。

相关包和文件:

软件包:autofs

服务文件:/usr/lib/systemd/system/autofs.service

配置文件:/etc/auto.master

autofs工具简单使用

#安装autofs工具
[root@rhel82 ~]# yum install -y autofs

启动autofs服务

[root@rhel82 ~]# systemctl start autofs

autofs服务启动后会生成/misc/cd目录,设置虚拟机连接光盘,实现自动挂载系统光盘

[root@rhel82 ~]# ll /misc/ 总用量 0

[root@rhel82 ~]# cd /misc/cd [root@rhel82 cd]# df -h 文件系统 容量 已用 可用 已用% 挂载点 devtmpfs 1.9G 0 1.9G 0% /dev tmpfs 2.0G 0 2.0G 0% /dev/shm tmpfs 2.0G 10M 2.0G 1% /run tmpfs 2.0G 0 2.0G 0% /sys/fs/cgroup /dev/nvme0n1p5 25G 4.4G 21G 18% / /dev/nvme0n1p2 1014M 208M 807M 21% /boot tmpfs 392M 1.2M 391M 1% /run/user/42 tmpfs 392M 4.6M 387M 2% /run/user/0 /dev/sr0 7.9G 7.9G 0 100% /misc/cd

[root@rhel82 ~]# rpm -ql autofs [root@rhel82 ~]# rpm -qc autofs

autofs配置详细说明

查看帮助:man 5 autofs

自动挂载资源有两种格式

相对路径挂载法

将mount point挂载点路径分为dirname和basename分别配置,可能会影响现有的目录结构

# 例如挂载光盘: mount /dev/sr0 /mnt/sr0,其中/mnt目录为dirname,/mnt/sr0为basename,相当于/mnt/sr0 = /dirname/basename

autofs主配置文件/etc/auto.master格式

挂载点的dirname指定目录的配置文件路径,如:/etc/test.auto

指定子配置文件格式/etc/test.auto

挂载点的basename挂载选项选项设备

注意:autofs配置的dirname目录和basename目录不需要手动创建,会覆盖已存在挂载点的dirname目录下原数据

autofs默认提供挂载光盘范例

[root@Centos8 ~]# cat /etc/auto.master
/misc   /etc/auto.misc

[root@centos8 ~]# cat /etc/auto.misc cd -fstype=iso9660,ro,nosuid,nodev :/dev/cdrom

特殊写法:挂载点dataname和挂载目录dataname相同,即:mount 10.0.0.18:/data/www /misc/www

  • -fstype=nfs 10.0.0.18:/data/&

范例:利用autofs自动挂载NFS

#服务端和客户端安装nfs-utils工具包
[root@server ~]# yum install -y nfs-utils
[root@client ~]# yum install -y nfs-utils
[root@server ~]# mkdir /nfs
[root@server ~]# cp /etc/passwd /nfs/

centos6系统nfs服务叫做nfs.service

centos7系统上nfs.service和nfs-server.service同一个服务

centos8只有nfs-server.service服务

[root@server ~]# systemctl start nfs

centos7系统可以解决服务之间依赖关系,并且nfs服务启动会自动启动rpcbind.service

[root@server ~]# systemctl status rpcbind

[root@server ~]# vim /etc/exports /nfs *(rw)

[root@server ~]# exportfs -r [root@server ~]# exportfs -v /nfs (sync,wdelay,hide,no_subtree_check,sec=sys,rw,root_squash,no_all_squash)

[root@server ~]# systemctl restart nfs [root@server ~]# showmount -e 192.168.192.128 Export list for 192.168.192.128: /nfs *

[root@client ~]# showmount -e 192.168.192.128 Export list for 192.168.192.128: /nfs *

[root@client ~]# mkdir /opt/nfs [root@client ~]# mount 192.168.192.128:/nfs /opt/nfs/ [root@client ~]# df -h | grep nfs 192.168.192.128:/nfs 62G 1.7G 61G 3% /opt/nfs

编写autofs主配置文件

[root@client ~]# vim /etc/auto.master /opt /etc/auto.master.d/auto.nfs

编写子配置文件

[root@client ~]# vim /etc/auto.master.d/auto.nfs nfs -fstype=nfs 192.168.192.128:/nfs

挂载点/dirname是/目录,查看autofs配置未生效,/目录数据

[root@client ~]# cp /root/anaconda-ks.cfg /opt/ [root@client ~]# ll /opt/ 总用量 4 -rw-------. 1 root root 1453 12月 5 04:03 anaconda-ks.cfg

如果修改主配置文件需要重启服务

[root@client ~]# systemctl restart autofs

一旦重启autofs服务,挂载dirname目录属于autofs服务管理,源数据不存在

[root@centos8 ~]# ll /opt/ total 0

cd进入指定挂载点,autofs就会自动挂载

[root@client ~]# ls /opt/ [root@client ~]# cd /opt/nfs [root@client nfs]# ls passwd

[root@client nfs]# df -h | grep nfs 192.168.192.128:/nfs 62G 1.7G 61G 3% /opt/nfs

绝对路径挂载法

直接匹配全部的绝对路径名称,都写入到指定的配置文件里,不会影响本地目录结构

autofs主配置文件/etc/auto.master格式

/- 指定目录的配置文件路径(使用/-表示使用绝对目录)

指定子配置文件格式/etc/test.auto

挂载点绝对路径挂载选项选项设备

范例

[root@client ~]# vim /etc/auto.master
/-     /etc/auto.master.d/auto.nfs

[root@client ~]# vim /etc/auto.master.d/auto.nfs /opt/nfs -fstype=nfs 192.168.192.128:/nfs

autofs服务使用绝对路径自动挂载,不会覆盖原数据

[root@client ~]# systemctl start autofs [root@client ~]# ll /opt/ 总用量 4 -rw-------. 1 root root 1453 12月 5 04:03 anaconda-ks.cfg drwxr-xr-x. 2 root root 20 12月 4 19:39 nfs

[root@client ~]# cd /opt/nfs/ [root@client nfs]# ls passwd

优化Linux系统性能

使用tuned-adm命令优化Linux系统性能。作为系统管理员,可以通过调整各种设置来优化Linux系统的性能,以适应当前用例的工作负载,帮助提升Linux的性能。

可以调整的可用配置文件:

  • balanced:非常适合在节能和性能之间寻求折衷的系统。
  • desktop:源自平衡配置文件,提供交互式应用程序的更快响应。
  • throughput-performance:调整系统以获得最大吞吐量。
  • latency-performance:对于要求低延迟,以功耗为代价的服务器系统的理想选择。
  • network-latency:源自延迟性能配置文件,它启用其他网络调整参数以提供较低的网络延迟。
  • network-throughput:从吞吐量性能概要文件得出,附加的网络调整参数适用于最大的网络吞吐量。
  • powersave:调整系统以最大程度地节省电力。
  • oracle:基于吞吐量性能概要文件针对Oracle数据库负载进行了优化。
  • virtual-guest:优化以在虚拟访客中运行。
  • virtual-host:如果用于运行KVM guest虚拟机,请调整系统以获得最佳性能。

安装Tuned

[root@rhel82 ~]# yum install tuned -y

[root@rhel82 ~]# systemctl status tuned

选择调整配置文件

调整的配置文件包含性能提升配置文件,性能提升配置文件包括侧重于:存储和网络的低延迟、高吞吐量的存储和网络、虚拟主机性能、虚拟机性能的配置文件。

我们将使用tuned-adm命令来选择和应用这些配置文件。

检查当前活动的调优配置文件:

[root@rhel82 ~]# tuned-adm active
Current active profile: virtual-guest

可以使用更多配置文件,如下:

[root@rhel82 ~]# tuned-adm list
Available profiles:
  • accelerator-performance - Throughput performance based tuning with disabled higher latency STOP states
  • balanced - General non-specialized tuned profile
  • desktop - Optimize for the desktop use-case
  • hpc-compute - Optimize for HPC compute workloads
  • intel-sst - Configure for Intel Speed Select Base Frequency
  • latency-performance - Optimize for deterministic performance at the cost of increased power consumption
  • network-latency - Optimize for deterministic performance at the cost of increased power consumption, focused on low latency network performance
  • network-throughput - Optimize for streaming network throughput, generally only necessary on older CPUs or 40G+ networks
  • optimize-serial-console - Optimize for serial console use.
  • powersave - Optimize for low power consumption
  • throughput-performance - Broadly applicable tuning that provides excellent performance across a variety of common server workloads
  • virtual-guest - Optimize for running inside a virtual guest
  • virtual-host - Optimize for running KVM guests Current active profile: virtual-guest

tuned-adm配置文件命令用于将活动配置文件切换到其他配置文件,此示例将调整我们的系统以实现最大吞吐量:

[root@rhel82 ~]# tuned-adm profile throughput-performance

确认当前配置文件:

[root@rhel82 ~]# tuned-adm active
Current active profile: throughput-performance

检查系统推荐的调整配置文件

tuned-adm命令还可以建议系统的调整配置文件,这基于各种系统特征,包括系统是否为虚拟机以及在系统安装期间选择的其他预定义类别:

[root@rhel82 ~]# tuned-adm recommend
virtual-guest

然后,可以将个人资料设置为推荐值:

[root@rhel82 ~]# tuned-adm profile virtual-guest

查看配置文件详细信息,请运行:

[root@rhel82 ~]# tuned-adm profile_info virtual-guest
Profile name:
virtual-guest

Profile summary: Optimize for running inside a virtual guest

Profile description:

关闭已调优的调整活动:

[root@rhel82 ~]# tuned-adm off

[root@rhel82 ~]# tuned-adm active No current active profile.

好了,本文到此结束,带大家了解了《Linuxautofs自动挂载详解与实现攻略》,希望本文对你有所帮助!关注golang学习网公众号,给大家分享更多科技周边知识!
